Issue Volume 1, Number 6

CLICK HERE to see the complete V1N6 issue layout!

Artwork below is reduced in resolution from that in the article.

Issue V1N6 of the new electronic APR (PDF file format on CD-ROM) features four main articles. The primary article in this issue is a 50+-page article on American submarine aircraft carrier projects since the 1920's. Described are the Boeing AN-1 submarine design from 1958, designed to carry eight Mach 3 VTOL strike planes; a 1963 General Dynamics concept for a truly massive sub that could carry more than 40 VTOL fighters; US Navy designs from the early '20's; and several aircraft meant to operate from submarines. Many diagrams, including detailed inboard views, are provided.





The next article is a 10-page article by Dennis R. Jenkins about a 1960 North American Aviation concept for a self-deploying space station. This Saturn V-launched design would form a toroidal structure and would rotate for artificial gravity. This article contains diagrams as well as artwork and drawings of related artificial gravity space stations.


Also included is an 9-page article by Bill Slayton on Lockheed CL-346 F-104-derived VTOL fighter/bomber concepts. Includes numerous layout, inboard and component drawings of six different designs, including tilt-jet and tailsitter concepts.

An 8-page article on the Junkers RT 8-1-01 "Raumtransporter," a 1960's German design for a small, manned fully-reusable two-stage-to-orbit spaceplane. Includes artwork, diagrams and all-new drawings.


Lastly, small articles ("Aerospace History Nuggets") on several minor design concepts, including:
Vought V-524 tailless VTOL fighter
Boeing Model 767-732, a double-decker jetliner with very unusual wings




V1N6 download order: $8.00
